Powertrain Electrification Transmissions

Multi Speed Reducer

Last update: 02 Sep. 2024

What is a mutli-speed or variable speed reducer?

The multi-speed transmission is a cost-effective solution to limit CO2 emissions on hybid vehicles and to lower the battery cost on electric cars. This 2-speed reducer, or gear reducer, solution allows to improve the efficiency of the powertrain by using different gear ratio to ensure optimum efficiency in all driving conditions. The first gear improves the torque at low speed for towing and take off applications while the second gear improves the speed and the range of the vehicle.

0/0

What are Valeo Multi-speed Reducer benefits?

  • Increase towing capacity
  • Enhance Take-off
  • Enabler of all-wheel drive capacity
  • All optimum driving experience with high torque at low speed and boost en at high speed
  • Multi-speed allows to have neutral position for a free disconnect function
  • Cost-effective solution

Valeo Multi speed reducer specifications

  • Peak motoring power = 23kW @ 48 VDC
  • Max input torque = 89 Nm
  • Max torque at wheel = 1800 Nm
  • Max speed output = 1400 rpm
  • Ratio 1st & 2nd = 21,69 & 11,38
  • Max reducer efficiency = above 97%

Vehicle type

  • Passenger car
  • Bus
  • Truck
  • Robot taxi
  • Motorcycle
  • Bike
  • Droid
  • Off road
