Powertrain Electrification Electric Axles

High Voltage 300kW Electric Axle

Last update: 15 Jan. 2024

What is Valeo Electric Axle?

This electric axle is the high-end version of Valeo High Voltage eAxle platform. It has a peak power of 300kW and has been developped to equip the flagship sedan of a luxury German OEM. It is a fully integrated system with the electric motor, inverter and reducer. It offers great NVH behaviour, excellent efficiency and the vehicle has a WLTP combined electric energy consumption between 15.7 and 19.8 kWh/100 km. The eAxle platform is scalable with additionnal fixtures like parklock and disconnect.


What are Valeo electric Axle benefits?

  • Full system integrating eMotor, inverter and reducer
  • Optimized system packaging for great NVH behaviour
  • Innovative oil cooling design
  • Low weight, compact and efficiency-optimized design (up to 95% for electric drive system)
  • Customer-specific software integration
  • Park lock system, differential and disconnect unit available as an option

Valeo electric Axle specifications

  • Peak power from 180 kW up to 300 kW
  • Peak wheel torque up to 5,700 Nm
  • Max. eMotor speed up to 18,000 rpm
  • System weight ~125 kg
  • Park lock system, differential and disconnect unit available as an option
  • Forced gearbox cooling for high speeds
  • EMC level 5, ASIL D
  • 2021

    In production since 2021

Vehicle type

  • Passenger car
  • Bus
  • Truck
  • Robot taxi
  • Motorcycle
  • Bike
  • Droid
  • Off road
